CNC lathe and CNC milling machine

　　Although both CNC lathes and CNC milling machines belong to the category of CNC machine tools, they have significant differences in multiple aspects. The following is a detailed analysis of the differences between the two:

　　1、 Application scope

　　CNC lathe: mainly used for machining rotary parts such as shafts, disks, etc. It can perform various machining processes such as outer circle, inner circle, end face, gears, etc., and is particularly suitable for machining circular parts with larger diameters. These parts have a wide range of applications in industries such as automobiles, ships, and machinery.

　　Numerical control milling machine: It is widely used for machining various complex shapes of planes, surfaces, grooves, etc. It can perform multi axis and multi-directional cutting, suitable for industries such as aerospace, electronics, and molds that require high requirements for part shape and accuracy.

　　2、 Structural characteristics

　　CNC lathe: mainly composed of bed body, bed frame, spindle box, lubrication system, feed system, cutting tools, and clamping device. The turret and spindle generally adopt an integrated design, which helps to improve machining accuracy.

　　CNC milling machine: The structure includes the bed, supporting worktable, spindle, feed system, lubrication system, and CNC system. Unlike CNC lathes, the tool magazine and spindle of CNC milling machines can be independently adjusted, which gives them higher flexibility.

　　3、 Processing method

　　CNC lathe: mainly uses turning machining method to process workpieces through the rotation of cutting tools. During the machining process, the workpiece is fixed on the spindle and rotates, while the cutting tool cuts along a pre-set path.

　　CNC milling machine: It adopts milling processing method to machine workpieces through the feed and rotation of cutting tools. During the machining process, the workpiece is fixed on the worktable, and the milling cutter moves in different directions to cut according to a pre-set path.

　　4、 Tool selection

　　CNC lathe: Due to the limitations of machining methods, its tool types are relatively single and mainly used for turning machining.

　　CNC milling machines have a wider range of tool types, including milling cutters, drills, reamers, and other types, to meet the machining needs of different shapes and materials.

　　5、 Processing accuracy and efficiency

　　Both have advantages in machining accuracy and efficiency. CNC lathes typically have high machining accuracy due to their integrated design and stable turning methods. CNC milling machines, on the other hand, exhibit higher efficiency and flexibility in machining complex shaped parts due to their flexibility and wide selection of cutting tools.
